Balboa BP7 with TP500 Bundle , 4.0 kW G6405

With 7 relays, the BP7 has 32 different setups and can power a spa with 1-4 pumps, including Microsilk systems. Can also replace any Balboa BP System* while using the existing topside that is already installed on the spa. Will replace any Balboa VS or EL System* when you match it with any TP or SpaTouch topside panel. Will replace any Balboa or other brand’s non-low flow system* when you match it with any TP or SpaTouch topside panel. This system can only be wired 220v.

G6405 BP7 Programming And topside Configuration click  HERE

Features:

• Supports all TP and SpaTouch topsides
• Supports all BP ancillary products (ControlMySpa, BBA, CZ, and Status Pro)
• Plug-N-Click Heater
• WiFi Included

Kit Includes:

• G4361 – Balboa BP7 System with 4.0kW Heater
• G8450 – Balboa TP500 Panel, Less Overlay
• 17183 – TP500 Panel Overlay (6-Button, Rectangle)
• 25098 – Wire Assembly, 8ft for spa light
• 15480 – Panel Bezel (Adapter Plate)

-CAN REPLACE ANY BP BALBOA SYSTEM* – While using the existing topside that is already installed on the spa

-CAN REPLACE ANY BALBOA VS OR EL SYSTEM* – When you match it with any TP or SpaTouch™ topside panel

*Both the Circ pump and Ozone can be converted to 120V, however, they will be the same voltage after conversion. (Both 120V or both 240V.)

*If a 24-hour circulation pump is being installed, it must have no less than a 23 GPM flow. Laing, Grundfos, or Waterway Tiny Might pumps do not perform at this rate and cannot be used.
