Circuit Board Jacuzzi / Sundance LX-15 LED Rev 5.60A NON-CIRC

0 out of 5
( There are no reviews yet. )

$609.89

Availability: 3 in stock SKU: 6600-720 Category:
Add to wishlist

Circuit Board Jacuzzi / Sundance LX-15 LED Rev 5.60A NON-CIRC

$609.89

In stock

Description

LED Circuit board for Jacuzzi and Sundance

Rev 5.60A

Uses a 8 pin phone style connector & molex connector

  • 2 Pump (LX15)
  • Original Part 6600-087 (2-Pmp No Circ pump)
    Changed to 6600-287
    Changed to 6600-046*
    end of 2017 6600-720*

  • Replaces the follwowing PCB’s:
  • 3-60-0095 , 6600-046 , 6600-087 , 6600-204 , 6600-287 , 6600-720 , SD6600-287 , SD6600-720

    PCB Jumper Settitngs

  • Jumper1–15A on/50A off
  • Jumper2–2 pumps on/ 1 pump off
  • Jumper3–Use in conjunction with jumper 2
  • Jumper4–Centigrade on/ Fahrenheit off

    Pump 2 hook up:

  • J-15 = White
  • J-16 = Black
  • J-17 = Red
